Transparent Heaters
Fullchance is a leading manufacturer of glass heaters for the flat‑panel display industry. Typically, the heaters are I.M.ITO™, available for epoxy or air use, for freestanding or laminated applications. The heaters are designed for 0.1 W/sq. in. – 5 W/sq. in.
Fullchance has developed a unique software process that predicts heat dissipation, power loading and temperature rise in different environments, making them robust and durable.
Fullchance is also a leading heater manufacturer for sapphire and silicon substrates, utilizing deposition of metals and/or oxides deposited in a grid‑like pattern. They deliver power up to 20 W/sq. in. and transmittance as high as 95 % across the 0.8 µm – 6.5 µm range. Ideal for near‑infrared and infrared applications.
Substrate Specifications
Product Size
Processing:
Substrate Specifications
| glass |
Corning Eagle XG, Eagle 2000, Borafloat, standard float (soda‑lime) glass
Tempered glass: chemical or heat tempering
|
| Glass Craft | Chemical or heat‑tempered toughened glass |
| thickness |
The standard thickness ranges from 0.01 inches (0.25 mm) to 0.5 inches (12.7 mm).
(For special thickness requirements, please contact Saint Berlin.)
70 µm and 100 µm are available upon special request.
|
Product Size
| Standard Version | All areas of 1/2" or circular, maximum 24" x 24" (610 mm x 610 mm) |
| texture | Sizes range from 1/2" square to 14" x 18" (355 mm x 457 mm) |
| Multiple sizes and shapes |
circular
sheet‑shaped
square or trapezoidal
|
| Dimensional tolerance: ± 0.002" (0.05 mm) | |
Processing:
Ion Beam Sputtering (Advanced Process)
Scope of Application:
Commercial displays, avionics and military displays
Coating Non‑Uniformity
Full sheet ±2.5%
Bus Bars:
1: Sputtered Cr / Ni / Au, Reflow Soldering, 10K PSI (Pull Test)
2: Flex Cable
3: Wrap‑Around (See Figure)
Surface Quality:
Defects: Less than 5 μm on large substrates
Embedded Particles <2 μm
Surface Roughness: <20 Å RMS per side
Inspection Quality:
80/50 to 20/10 (5K Lux)
Thermal Imaging
Durability:
Abrasion: 200 Strokes @ 10 Kgm (Mil‑C‑675)
Adhesion: Quick Test (Mil‑M‑13508)
Solubility: >24 Hours in Sodium Chloride, Fog and Solution (Mil‑C‑675)
Temperature: >12 Hours @ ‑55 to 350 °C
Packaging:
Class 100, or as required.
