Product Description
1. Applications of Transparent Anti‑Fog Film
This electric heating product is specially designed to completely eliminate fogging on object surfaces. It has been widely applied in hotels, residential buildings, bathhouses, luxury yachts and other scenarios where transparency is required.
2. Working Principle and Characteristics of Transparent Anti‑Fog Film
The transparent anti‑fog film efficiently converts electric energy into thermal energy and conducts heat directly to the object surface. It raises the surface temperature to prevent water vapor from condensing on the mirror surface, so as to achieve the anti‑fog effect. The rated input power of the anti‑fog film maintains a stable mirror‑surface temperature for effective energy saving. With a thickness of merely 0.4 mm, it can be fully attached to the object surface, transferring heat to the object with high efficiency, reducing heat loss and realizing anti‑fog performance.
Technical Parameters of Transparent Anti‑Fog Film
Voltage: 12‑36 V
Input Power: 1.8‑2.5 W/dm²
Film Thickness: 0.4 mm
Mirror Surface Temperature Rise: 15‑18 ℃
Adhesion Strength: 0.5 kg/cm
Precautions for Anti‑Fog Film Installation
Do not pull the power cord of the anti‑fog film forcibly to avoid damaging the heating circuit.
Do not fold it forcefully. Do not cut or punch holes on the film by yourself. Avoid mechanical damage such as scratches caused by sharp tools.
The anti‑fog film is best installed in an environment above 1 ℃. The mirror back and film surface shall be dry and clean to prevent moisture.
Only neutral sealant shall be used. Acidic or alkaline sealants are strictly prohibited, otherwise the silver‑plated layer of the mirror will be damaged.
Route the power wire through the pre‑reserved outlet. Prevent the power cord from curling behind the mirror, which may result in uneven mirror mounting.
Slight expansion of the mirror lens may occur when the transparent anti‑fog film is in operation. Reserve an elastic clearance of more than 1 mm along the mirror edge during installation.
