The elements are easy to adapt to different shapes and patterns and and can be bespoke manufactured for higher volume applications.
These heating elements are intended for contact heating of flat surfaces and for heating of liquids through a flat wall. Compared with an ordinary tubular heating element, a heating element on a sheet metal provides substantially better heat transfer into a flat wall. These elements can also be of benefit in applications, where low thickness of the heating element is important.
hick film elements - Technical data
Suitable for applications where extra fast heating of flowing liquid is required. Ideal heat transfer is guaranteed by flowing of liquid through all inner surface of the heating element. The small dimensions of the element enables usage and placement in applications with limited space.
 |
Benefits & Applications
|
|
Material |
Thick film on plane plate of stainless steel, AISI 304/EN 1.4301 |
|---|---|
|
Dimension |
Max length, width, height 150 mm |
|
Assembly |
Fixing to the object |
|
Connection |
Flat connectors, Cable |
|
Others |
Operating temperature max 500°C |
