Silicone Heater for Small Diameter Pipes and Tubing

Description

Need to heat small OD pipes and tubing? We have the solution right here- Fullchance's spiral silicone rubber heaters can be made in a variety of diameters and is ALREADY pre-formed to the proper diameter for your application.

This ensures proper contact and makes installation of our small tube heaters a breeze.

FullchanceInc. designs and manufactures silicone rubber heaters for pipes and tubes, however, manufacturing techniques for our standard preformed heaters meant that for small diameter pipes the heater could only be manufactured in short lengths for rigid pipe work. Through continued product development, Fullchance can now offer the Spiral Wrap Heater range to suit flexible or rigid pipes

Key Features

Our small tube heaters are suitable for straight or curved pipe sections
Rugged spiral heating element, able to be flexed as part of normal operation
Easy to install
Options for temperature sensors to be installed in the heater provide accurate temperature control with a suitable controller (see the list of our Temperature Controllers)
Our pipe wrap heater is able to stand alone or be connected in parallel option to accommodate for longer runs

Specification

Pipe heater wrap is made of robust silicone rubber coated glass fiber fabric
Maximum operating temperature of 392°F/200°C
Standard range to suit 1/4” (6.35mm) outer diameter pipe in six different lengths
Small tube heaters can be customized to suit customer specific pipe diameter, length and Voltage
Typical power density approximately 2.0W/inch
Supplied with 20″ long PTFE supply leads as standard for single heater installation but can also be
manufactured with 2 pairs of supply leads for parallel connection in a multi heater installation
We can make a spiral heating element with optional temperature sensors, typically surface mounted Thermocouple or RTD

Applications

Fluid or Gas delivery systems
Semi-conductor processes
Frost protection
Anti-condensation
Heat loss maintenance in preheated systems
